Chapter 7: Form in Architecture
Rita Tekippe, Jeffrey LeMieux, and Pamela J. Sachant
7.1 LEARNING OUTCOMES
After completing this chapter, you should be able to:
Understand the differences between function and form in architecture
Understand how form and function work together in architecture created for different purposes
Understand different types and uses of architecture
7.2 INTRODUCTION
So far, we have given very little consideration to architecture, yet it is one of the most culturally significant forms of art. Often, with structures that were built for group activities, they reflect the culture, its values, style, purposes, and preferences in the time and place more broadly and deeply than settings where individual choices might predominate. And decoration of such architectural settings, even if individual needs and ideals have been expressed through painting or sculptural themes, generally reflects the greater permanence of a structure expected to serve the group’s purposes and needs.
The earliest buildings were likely designed to shelter a family or small group that lived together. Soon group needs came into play, and the community may have wanted to provide for joint activities of several types such as ritual/worship, group protection, government, markets, and other commercial needs. The types expanded as the societies grew, diversified, specialized, and sought ways to meet needs for both individuals and communities. The specific purposes led to diverse designs, and cultural values influenced both practical and stylistic choices. We will survey a small sample of landmark types from across the centuries from several different viewpoints, depending upon the significance of features for the individual examples. Our focus will sometimes be on the plan or layout of the structure, materials used in its creation, or spatial considerations as they relate to purposes and use. At other times, we will look at how the building is situated within a community, or how patrons, owners, and community members influence its construction and use. We will examine in greater detail the ritual uses, meanings, and significance of architectural settings and their decoration, in Chapter 10 Art and Ritual Life: Symbolism of Space and Ritual Objects.
Before we start our discussion, you should familiarize yourself with the basics of building, that is, how you might create walls and place openings in the walls while supporting the parts of the structure above. The most basic method is the post-and-lintel design in which two upright beams support a horizontal one to create a rectangular opening. (Figure 7.1) Before long, builders also devised a variety of arches, a curved or pointed structure spanning an opening and supporting the weight above, and then created further modifications of these techniques to develop barrel vaults, a series of circular arches that form a ceiling or roof, and domes, spherical-shaped ceiling or roof. (Diagram of Roman Arches; Domes) They also made variations that served decorative purposes. Over time, these have been imaginatively used for a tremendous variety of structural and decorative purposes, and you should keep them in mind as we investigate an array of buildings that reflect cultural concerns and human needs of all sorts. We will classify these buildings into several groups, although noting that a great number of them were multipurpose: residential/housing, community needs, commercial buildings and centers, governmental structures, and those designed for worship.
Figure 7.1 | Diagram Showing Lintel and Posts
Author: Corey Parson
Source: Original Work
License: CC BY-SA 4.0
7.3 RESIDENTIAL NEEDS
The earliest types of shelters were likely caves found by humans as they wandered to hunt and gather food and to find refuge from bad weather or pursuing creatures. The first independently standing structures were made of materials that were impermanent, that is, those found in nature—sticks, bones, animal pelts—and fashioned to create a covered space apparently as a protection from the elements. We have little evidence left for us to know fully how they were built and used, but some vestiges do remain that have enabled scholars to make reconstructions. (Figure 7.2)
Figure 7.2 | Reconstructed Jōmon period (3000 BC) houses.
Author: User “Qurren”
Source: Wikimedia Commons
License: CC BY-SA 3.0
As people became more settled, domesticated animals, and cultivated crops, they developed such construction techniques as wattle-and-daub (sticks covered with mud), rammed earth (moist dirt and sand or gravel compressed into a temporary frame), and clay bricks (unfired and fired that developed alongside their evolving techniques for creating pottery vessels). (Drawing depicting architectural structure of Chinese round houses) (Figure 7.3)
Figure 7.3 | Recreation of a Celtic Roundhouse
Author: User “FruitMonkey”
Source: Wikimedia Commons
License: Public Domain
They used these methods for communal living centers such as the village of Catalhöyük in modern Turkey (7,500-5,700 BCE), including common walls so that the clustered houses supported one another. (Figure 7.4) Such building methods addressed security issues by confining entry into living spaces to openings in the roofs, with ladders that could be retracted to foil trespassers. All of these types had certain common features to meet such everyday needs as warmth, cooking, sleeping, and storage, and were usually centered around a hearth with provision for smoke ventilation. Catalhöyük also included rooms that may have been for other common purposes, varying from shrines to serving as bakeries.
Figure 7.4 | Çatalhöyük at the Time of the First Excavations
Author: User “Omar hoftun” Source: Wikimedia Commons License: CC BY-SA 3.0
The use of stone for building structures began in prehistoric times, and an example of such a structure can be seen the Scottish village of Skara Brae (3,180-2,500 BCE). The walls were made of stacked stone while entryways and some of the furniture were created using the post-and-lintel method. (Figure 7.5) Because of the harsh northern climate, the structures were partially underground for protection from the elements. Additionally, covered walkways were created to facilitate movement among its eight units. Seven of these units apparently accommodated a family or small group, while the eighth was a common room, perhaps a workshop. In addition to cultivating crops, these villagers likely herded, fished, and hunted for food. Stone furnishing such as seating, beds, storage spaces, and other items within the single-room units were around a central fire pit. (Figure 7.6)
Figure 7.5 | Old settlement Sjara Brae in Orkney Island, Scotland
Author: User “Chmee2”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.6 | Inside a house at Skara Brae
Author: User “John Allan”
Source: Wikimedia Commons
License: CC BY-SA 2.0
With these basic methods, the humble shelter types of the Neolithic Age (c. 7,000-c. 1,700 BCE) and overlapping Chalcolithic (Copper) Age (c. 5,500-c. 1,700 BCE) provided a foundation for buildings of every sort used throughout history (with considerable elaboration of residential structures for the powerful and wealthy). Material choices eventually expanded to include first wood, brick, and stone, and later concrete and metal.
Residential palaces appeared by the time of the two great early civilizations of the Ancient Near East, Mesopotamia and Egypt, as well as those of the Aegean Sea: Crete, Cyclades, and mainland Greece prior to the development of the Greek Empire. The Palace at Knossos on the island of Crete was a grand residence for rulers of the Minoan civilization; the palace was built c. 1,700 BCE, after an earlier structure was destroyed by an earthquake, and abandoned between 1,380 and 1,100 BCE. (Drawing of Knossos) The sprawling complex included residential areas, throne rooms, a central courtyard, and food storage magazines for crops and seafood used in the commercial trading, an important industry and mainstay in sustaining the people. (Floorplan of Residential Palace) An island civilization, the Minoans were in the rare position of not having to protect themselves from enemies. The Palace at Knossos and similar structures on Crete were not fortified, that is, built behind solid walls and gates to hold off invaders. The palaces were instead built with windows and colonnades, or covered rows of columns, on their exteriors, allowing free circulation of light and air.
Another palace complex, that of Neo-Assyrian King Sargon II (ruled 722-705 BCE) at DurSharrukin, today Khorsabad in Iran, was clearly much more militaristic in character, evident by the surrounding defensive walls that strictly controlled access to the royal precincts. (Figure 7.7) Even after passage through a complex and imposing gateway, one had to cross guarded courtyards and passageways to approach the king’s throne room. The structural presence was one of imposing power, as you can see from the enormous towered main portal. (Figure 7.8) To intimidate the visitor, interior decorations further asserted the mighty and ferocious nature of Sargon II with wall carvings depicting victorious battles. The complex also included temples for worship of the deities as well as quarters for high-ranking officials and servants.
Figure 7.7 | Model of Palace of Sargon at Khosrabad
Author: Internet Archive Book Images
Source: Wikimedia Commons
License: Public Domain
Figure 7.8 | Palace of Dur-Sharrukin
Author: Encyclopedia Britannica Source: Wikimedia Commons License: Public Domain
Later developments for residences include apartment buildings for urban dwellers; such multi-family dwellings have taken many forms over time, and we can view an early type, from the second-century CE Roman port town of Ostia Antica, called an insula, which is Latin for “island.” (Figure 7.9) In middle-class “apartments” such as these, there were stores and vendors’ stalls on the ground floor facing the street. In some versions, the lower floors were for the wealthier people, while upper floors decreased in cost and desirability. The basic ideas of how to accommodate multi-family living were established by this time and have remained similar since. What has changed over time are the material and decorations used, styles adopted, provisions for electricity, water, and sewage management, and eventually zoning policies that would dictate locations, sizes, required provisions for safety, and density of occupation.
Figure 7.9 | Ostian Insula
Author: User “Nashvilleneighbor”
Source: Wikimedia Commons
License: Public Domain
Private homes existed for the middle class and wealthy in towns and in the countryside; the latter were called villas whether they were primary residences or vacation homes. A private home in town might also have shops around its perimeter, but the accommodations for family life, entertainment, and conducting the owner’s business were generally contained in a single floor layout. (Diagram of Roman Villa: Villa.jpg) After passing through an entry from the street, one entered the atrium, a courtyard with a peristyle, a row of columns within a building often supporting a porch, left open to the sky with a pool in the center to catch rainwater. A private garden was in a second area open to the elements. The mild climate led to provisions for a good measure of outdoor living as well as fresh air and sunlight during much of the year, even including indoor and outdoor dining rooms. There were rooms for sleeping, storage, and household work off the atrium and garden, as well as a space for worship, known as the lararium. (Figure 7.10) Here, two Lares, or household gods, flank an ancestor figure; the snake below symbolizes fertility and prosperity.
Figure 7.10 | Scene from Lararium, House of the Vettii, Pompeii
Author: User “Patricio.lorente”
Source: Wikimedia Commons
License: CC BY-SA 2.5
Roman royalty had grand palaces, and we have good evidence of such from the retirement compound created for the Emperor Diocletian (r. 284-305 CE) in Split set on the Bay of Aspalathos in the Roman province of Dalmatia, today Croatia. (Figure 7.11) The walled precincts with defensive watchtowers and fortified gateways included housing for his military garrison, a central peristyle courtyard, three temples, and his mausoleum, the building housing his tomb. The design, perhaps fitting for the aggressive persecutor of Christians and retired general, was quite militaristic in many ways, resembling a Roman military encampment, or castrum. The private and public imperial areas were luxurious by contrast. Like most palace complexes, provisions were made to house soldiers and servants, and it was lavishly decorated throughout with frescos, sculptures, and mosaics, images or designs created on a wall or floor made up of small pieces of stone, tile, or glass.
Figure 7.11 | Diocletian’s Palace
Artist: Ernest Hébrard
Author: User “DIREKTOR”
Source: Wikimedia Commons
License: Public Domain
While the locations for palaces were always strategically selected, the rationale was not always defensive in character. When Charlemagne selected Aachen, Germany, as the site for his main palace (he had several), among the attractions were its centralized site within his growing empire and the healing waters of the natural spa there. In examining the reconstruction of his complex, you will notice the baths, shown to the left of the palace complex, are an important feature, as they had been in Roman society. (Figure 7.12) He had a large audience hall, a grand portal, courtyards, housing, and an impressive palace chapel, which is the major structure still standing. (see Figures 3.13 and 7.64)
Figure 7.12 | Palace of Aachen
Author: User “Aliesin”
Source: Wikimedia Commons
License: CC BY-SA 3.0
The church was an important statement for this model Christian ruler, and although it has been enlarged from its original central-plan design, the structure still carries notable features that were both impressive and influential for later medieval church architecture. Charlemagne’s throne was positioned on the gallery level, an upper level overlooking the floor below. (Figure 7.13) The throne was above the entrance to the church, with an enormous “window of appearance” above the portal facing out into the atrium courtyard, where Charlemagne could address his Christian subjects gathered there. This emphasis on the western entryway was developed into the grand western facades of Romanesque and Gothic churches. The Doge’s (Duke’s) Palace in Venice is another impressive statement of rulership wed to Christian leadership. (Figure 7.14) With its façade on the waterfront, the church of San Marco sitting directly behind it, state offices located across from it, and the communal, open-ended piazza, or courtyard, between them, the palace literally connects the secular, religious, social, and political realms of Venetian life. (Figure 7.15) Public courtyards at the heart of cities became typical during the Italian Renaissance, as did private, interior courtyards in the center of Italian homes for rulers, wealthy aristocrats, and high church officials. As an official governmental center and residence, this Venetian palace included private quarters for the Doge along with meeting rooms and council chambers, all richly decorated with marble, stucco, and fresco and including iconographic themes related to Venice, its history, and civic identity.
Figure 7.13 | The throne of Charlemagne and the subsequent German Kings in Aachen Cathedral.
Author: Bojin
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.14 | Doge’s Palace and St. Mark’s Tower, Venice
Author: User “Rambling Traveler”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.15 | Courtyard of Doge’s Palace
Author: User “Benh LIEU SONG”
Source: Wikimedia Commons
License: CC BY-SA 4.0
In Japan, the fourteenth-century Himeji Castle, built as a fort by the samurai Akamatsu Norimura, was situated dramatically atop Himeyana Hill. (Figure 7.16) Though a defensive posture was its primary motive, the great beauty and lyrical appearance of its curved walls and rooflines are its predominant effects. It has been called the “white heron” in response to the impression it gives of a great bird about to take flight. The complex, again, has many purposes and comprises eighty-three different structures. The grounds include huge warehouses, lush gardens, and intricate mazes. Despite its fairytale looks, its defensive systems are complex and effective, including moats, keeps, gates, towers, turrets, and mounts and brackets for a variety of weapons. It has withstood numerous attacks and natural disasters over the centuries.
Figure 7.16 | Himeji Castle, Japan
Author: User “Bernard Gagnon”
Source: Wikimedia Commons
License: CC BY-SA 3.0
The final such royal complex we will explore is the Potala Palace in Lhasa, Tibet, established in 1645 by the fifth Dalai Lama; the palace functioned as the spiritual and governmental center for Tibetan Buddhism until the fourteenth and current Dalai Lama, Tenzin Gyatso (b. 1935), fled for political refuge in 1959. (Figure 7.17) The basic purpose of the palace was that of a Buddhist monastery; its original foundation was centered on two chapels of historical and spiritual significance to the order of monks. The palace is named after Mount Potalaka, the mythical abode of the Bodhisattva of compassion, Avalokiteshvara, and the paradisiac implications are meaningful to devotees.
Figure 7.17 | The Potala Palace in Lhasa, Tibet
Author: User “Xiquinho”
Source: Wikimedia Commons
License: CC BY-SA 3.0
As at Himeji, the hillside is a striking component of its appearance, and the enormous complex makes a very dramatic presentation. Indeed, whether intended for defensive purposes or not, its imposing appearance is often a very important feature for royal architecture. The impression of this palace’s organic relationship to the mountain is enhanced by its sloping walls, flat roofs, and numerous stairways that lead to its various structures. The complex includes living quarters for the Dalai Lama and the monks as well as governmental offices, a seminary, assembly halls, shrines, libraries, storage rooms, and numerous chapels. It includes statues and portraits of historical and spiritual leaders and many devotional and didactic depictions painted on walls and banners, and works for meditation and prayer. Burial mounds and tombs contain the remains of lamas and important scriptures.
The residential structures of the wealthy of previous eras have often been lost to us; however, we can examine some of the aristocratic family homes of the last several centuries to gain insight into some of the additional trends for creating dwellings that go far beyond the need for simple shelter and that show some of the design ideas devised by artists and architects. The house created for Lord Burlington in 1729 in Chiswick, England, is a good example of the Neo-Palladian style of architecture. (Figure 7.18) Andrea Palladio (1508-1580, Italy), a Venetian Renaissance architect, deeply studied ancient Greek and Roman architecture and architectural theory and developed new designs based on those but better fit to the means, methods, and needs of his day. His ideas were popular and have remained widely influential throughout the West to this day.
Figure 7.18 | Chiswick House, London
Author: User “Patche99z”
Source: Wikimedia Commons
License: Public Domain
Lord Burlington created his neo-Palladian villa design under the influence of Palladio’s ideas and those of other related designers. The basic idea here derives from a combination of a Greek temple front and a Roman dome, here supported by an octagonal drum, or circular or multi-sided base. Lord Burlington planned the house to showcase his fine collection of pictures and furniture and his architectural library as well as to provide comfort for his family living there. Great attention was paid to the surrounding gardens, and their design was very much a part of the overall scheme. Inspired by Roman gardens, they were designed by his friend William Kent (c. 1685-1748, England), an architect and early landscape architect, and included classicizing statues and miniature temples of a sort that were popular in English gardens of the day, thereby providing interesting and restful stopping points to a refreshing stroll outdoors. The logic and order of the layout of the building and grounds as well as the villa’s sense of grandeur led to its admiration and emulation by other builders who sought a similar elegance.
The Neo-Palladian style was carried to the United States by Thomas Jefferson for the campus of the University of Virginia, the state capitol of Virginia, and his own home of Monticello, near Charlottesville, Virginia. (Figure 7.19) Jefferson adapted ideas he gathered while U.S. Ambassador to France by using humbler materials such as the red brick made from local clay that he considered a better choice for a less pretentious statement than marble or limestone. At Monticello, he also brought the structure lower to the ground and added a wooden balustrade, a railing supported by upright supports, to the roofline. Nonetheless, its Palladian design origins are clear. The interior of the house is full of provisions for Jefferson’s notable intellectual and work habits such as his bedroom that opened into his office, his workrooms, and his collections of American artifacts.
Figure 7.19 | Monticello, Charlottesville, VA
Photographer: Matt Kozlowski
Author: User “Moofpocket”
Source: Wikimedia Commons
License: CC BY-SA 3.0
In the United States of the late nineteenth-century Gilded Age (c. 1870-1900), a time of rapid technological, commercial, and economic expansion, wealthy industrialists built enormous mansions in cities and at the seaside resorts or mountain retreats they favored. Among these, the Vanderbilt family (whose wealth came from shipping and railroads) commissioned several notable residences, mostly in the French-inspired Beaux Arts style, a period and style known in the U.S. as the American Renaissance (1876-1917).
One of these residences was The Breakers in Newport, Rhode Island, a lavish resort area replete with such structures. (Figure 7.20) The oceanfront house, designed by Richard Morris Hunt (1827-1895, USA), has seventy rooms on five floors and covers nearly an acre of land on a thirteen-acre lot with elaborate gardens. It was built with the most lavish material such as marble and wood from around the world and was decorated with rich and sumptuous furniture, fittings, and valuable artwork, as can be seen here in the library. (Figure 7.21) Clearly a residential structure of this type went far beyond the simple needs of housing to shelter a family from the elements and served to make a very grand and ostentatious statement of wealth and power.
Figure 7.20 | The Breakers, Vanderbilt’s mansion in Newport, RI
Author: User “Menuett”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.21 | The library at The Breakers
Photographer: Matt Wade
Author: User “UpstateNYer”
Source: Wikimedia Commons
License: CC BY-SA 3.0
By contrast to design ideas of the architects who catered to the wealthiest Americans, a new conception for providing living space came into being in the early twentieth century with Frank Lloyd Wright, who developed what he called the Prairie Style. He sought to counter the blocky forms that had become the standard for American homes with a structural sweep that hugged the ground, echoed the landscape, and fostered communication between the spaces in the house and the natural elements around it.
Perhaps the epitome of this thinking was realized in Wright’s design for Falling Water, a western Pennsylvania mountain home he created for the Kaufmann family of Pittsburgh. (Figure 7.22) At their request, he incorporated elements of their favorite recreation spot into the design: the rocky outcrop where they held picnics is in the living room, and the adjacent Bear Run waterfall pours out beneath the house’s cantilevered terraces, self-supporting rigid structure projecting from the wall. Like most of Wright’s houses, the place has flowing interior space, a great number of windows, and abundant natural light, as well as carefully coordinated use of stone and wood to incorporate the structure into the natural setting.
Figure 7.22 | Fallingwater, Pennsylvania
Architect: Frank Lloyd Wright
Author: User “Daderot”
Source: Wikimedia Commons
License: CC0 Public Domain
7.4 COMMUNITY AND GOVERNMENT
Clearly, many of the palaces and complexes we have explored included accommodation of community government needs. There were others throughout history that had somewhat more pointed community needs in mind for their creation but were often combined with other purposes as well. From the time of the rise of the earliest civilizations, the needs for government and religious expression often coalesced.
In the Mesopotamian Valley of the ancient Near East, today Iraq and Iran, we see this exemplified in the structure of the Ziggurat of Ur. (Figures 7.23 and 7.24) With the idea that the deities resided in the heavens, the ziggurat was conceived as a man-made mountain that served as a base for the temple, raising it closer to the celestial regions where the deities were. The pathways to the temple at the summit were steep and the approach to the gods was appropriately aggrandized and formalized. At the same time, the basic platform structure was part of a complex that included the provisions for a variety of other community services, record keeping, and commercial and governmental functions. The compact complex was located at the center of the community and in many aspects became the hub of life.
Figure 7.23 | Ziggurat of Ur, Iraq
Author: User “Hardnfast”
Source: Wikimedia Commons
License: CC BY 3.0
Figure 7.24 | Digital Rendering of the Ziggurat of Ur
Author: User “wikiwikiyarou”
Source: Wikimedia Commons
License: Public Domain
The people of the ancient Near East built with mud brick, sometimes baked, that has not proven to be durable, so the remains of these structures, constructed from around 2,400 BCE until the sixth century BCE, are generally not well preserved. Still, there are sufficient clues in the ruins to reconstruct the ways they were built and used.
The Romans generally made provisions for community functions in the forum, an open public space at the center of each city; the cities were often laid out in a grid plan organized with areas dedicated to various types of industrial, commercial, communal, and residential needs.(The Master Plan of Verbonia) The number and types of buildings varied, but they often included temples, libraries, markets, public baths (thermae), and judicial structures. The Forum at the heart of Rome was the site of numerous architectural statements and additions for the public good that were created by successive rulers.
One of the most influential of the buildings in the Forum of Trajan in Rome was the Basilica Ulpia, a center for law courts, business, and public gatherings. (Figure 7.25) The basilica included a long and broad open center space, a nave, flanked by aisles that fluidly expanded the area. (Figure 7.26) This design provided a readily adaptable concept for other purposes, most notably perhaps the congregational space needed for Christian churches that would arise in later centuries as the Christian populace grew.
Figure 7.25 | Drawing depicting the Basilica Ulpia, Rome
Artist: Julien Guadet
Author: User “Joris”
Source: Wikimedia Commons
License: Public Domain
Figure 7.26 | Illustration Depicting the Basilica Ulpia
Author: Encyclopedia Britannica
Source: Wikimedia Commons
License: Public Domain
Significant community spaces sometimes have as their boundaries adjoining but separate architectural structures. These spaces are nonetheless important gathering places that need to be considered as such and in connection with the surrounding architecture that defines them. The National Mall in Washington, D.C., is one such place. (Figure 7.27) We identify it by its location within the capitol city and by its placement among all the government and other public/community buildings that line and define it. One only has to see it as a site for a presidential inauguration celebration or other large public gatherings to realize its significance as a community center.
Figure 7.27 | National Mall and Washington Monument, Washington, DC
Author: User “Christoph Radtke”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Community needs for ceremony and entertainment have been addressed with specifically purposed architectural works since antiquity as well. Both the Greek and the Romans designed and built theaters, outdoor structures for dramatic performances, and amphitheaters, round or oval buildings with a central space for events, that provided models for such structures to this day. (Figures 7.28 and 7.29) While the basic concepts were devised by the Greeks to present religious festivals and ritual dramas, the Romans with their great ingenuity in engineering and material development added considerably to the potential for these designs to cater to changing needs and broader applications.
Figure 7.28 | Theatre of Epidaurus
Author: User “Olecorre”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.29 | Colosseum in Rome
Author: User “Andreas Tille”
Source: Wikimedia Commons
License: CC BY-SA 4.0
One of the most important contributions to the history of architecture was the Roman development of concrete for use as building material. Its greater strength, flexibility, and potential for adaptation made concrete far superior to the cut stone used to that point. These advances enabled the Romans to create new architectural forms by expanding the types of vaulting and means of spanning space they had previously used. Both of these important community structures, the theater and the amphitheater, were enlarged and put to new uses because of the Roman architectural contributions. Pacific Island cultures, as do those of Native Americans, particularly venerate tribal heritage and so celebrate the communal events related to their heritage. Native North Americans of the Kwakiutl Nation created the clan totems, objects or animals that hold significance for a group of people, at the Wawadit’la, also known as the Mungo Martin House in honor of the chief and artist who built it in Victoria, British Columbia. (Figure 7.30) The recognition and celebration of their shared culture is expressed, as well, in the Meeting House of the Maori people at Waitangi, New Zealand, with its deep front porch and big open hall for group events. (Figures 7.31 and 7.32) Additionally, the carved and painted decorations inside and out have specific iconographic and symbolic significance for the individuals who gather together at such communal sites.
Figure 7.30 | Wawadit’la, also known as Mungo Martin House, a Kwakwaka’wakw “big house”, with heraldic pole.
Artist: Chief Mungo Martin
Author: Ryan Bushby
Source: Wikimedia Commons
License: CC BY-SA 2.5
Figure 7.31 | Whare at Waitangi Treaty House site
Author: User “Andy king50”
Source: Wikimedia Commons
License: CC BY-SA 4.0
Figure 7.32 | Waitangi in the Bay of Islands, New Zealand
Author: Phil Whitehouse
Source: Wikimedia Commons
License: CC BY 2.0
7.5 COMMERCE
Buildings for commerce have appeared over time. Early systems of trade and barter in some places eventually became formalized in ways that required marketplaces and commercial establishments with temporary or permanent housing. While open-air markets with vendor stalls continue to be used in many places, in others shops or full buildings evolved for commercial and service transactions.
An early example appeared in ancient Athens, Greece, in the area where the open market or agora, was also located. The Stoa of Attalos, built by King Attalos II of Pergamon (r. 159-133 BCE), was comprised of a two-story covered walkway made of marble and limestone with columns on one side and a closed wall on the other. (Figure 7.33) Along the closed wall, there were twenty-one rooms on each level with each room providing space for a shop. These rooms were similar in character and purpose to those we noted on the ground floors of Roman villas and apartment buildings, but they provided for a more concentrated shopping area.
Figure 7.33 | Church of the Holy Apostles and Museum of Ancient Agora
Author: User “A.Savin”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Our modern provisions for shopping centers and department stores were designed with different ideas about merchandising, sales, and consumerism but, as we have seen with the rapid rise of on-line shopping for durable and perishable goods, this scenario will likely be ever evolving. Indeed, grocery and department stores may become completely passé. But their development in the nineteenth and twentieth centuries presented new possibilities for architectural design.
An example is the Carson, Pirie, Scott and Company Store in Chicago, designed by Louis Sullivan (1856-1924, USA) and built in 1904. (Figure 7.34) One of the early applications for steel frame, or “skeleton frame,” construction that made the development of skyscrapers possible, this sort of building also opened new possibilities for retail and office space. Here, the large ground-floor windows and corner entrance could provide a great deal of display space for attracting pedestrians while the expansive multistory interior offered shoppers a wide array of goods, especially compared to the sorts of small shops and markets that had been its predecessors.
Figure 7.34 | Carson, Pirie, Scott and Company Building, Chicago, IL
Author: User “Beyond My Ken”
Source: Wikimedia Commons
License: CC BY-SA 4.0
Not only the structure but also the decorative approach was innovative, as Sullivan combined Beaux Arts ideas with Art Nouveau motifs in the building’s surface design. (Figure 7.35) The elaborate, curvilinear, plant-based motifs central to the Art Nouveau movement, c. 1890-1910, in cast metal relief panels above the doors and ground floor windows added to visual appeal for potential customers.
Figure 7.35 | The northwest entrance to the Carson, Pirie, Scott and Company Building
Author: User “Beyond My Ken”
Source: Wikimedia Commons
License: CC BY-SA 4.0
New designs emerged for other commercial firms in this era as well. The Austrian Postal Savings Bank in Vienna, Austria, designed by architect Otto Wagner (1841-1918, Austria) has a huge multi-story façade covering a broad open interior space on the ground level; its sleek and modern aesthetic was startlingly new and different when it was completed in 1905. (Figure 7.36) One of Wagner’s aims in the design was to create a sense of strength and solidity that engendered trust and a feeling of financial security in customers. The main banking customer area is filled with natural light. Wagner used marble, steel, and polished glass for the simplified decoration of the reinforced concrete building, turning away from the Art Nouveau aesthetic and replacing it with his sense of modernism.
Figure 7.36 | The Austrian Postal Savings Bank in Vienna, Austria
Author: User “Extrawurst”
Source: Wikimedia Commons
License: CC BY-SA 3.0
The use of steel and reinforced concrete that facilitated the advent of the skyscraper truly revolutionized architecture and began a contest for height that continues today. Wealthy entrepreneurs and ambitious developers from around the world have joined in the competition for buildings of modern distinction. One example is the Chrysler Building in New York City, designed by William van Alen (1883-1954, USA). (Figure 7.37) Its décor in the Art Deco style (c. 1920-1940), including the ribbed, sunburst pattern made of stainless steel in the building’s terraced crown, celebrates American industrialism and the automobile. At 1,046 feet, the Chrysler Building was for eleven months after its completion in 1930 the tallest in the world. (It was surpassed in 1931 by the Empire State Building at 1,454 feet.)
Figure 7.37 | The Top of the Chrysler Building, New York City, NY
Author: User “Leena Hietanen”
Source: Wikimedia Commons
License: CC BY-SA 3.0
A more recent example is the Petronas Twin Towers in Kuala Lampur, Malaysia, designed by César Pelli (b. 1926, Argentina, lives USA). (Figure 7.38) Inaugurated in 1999, they were the tallest buildings for several years and remain the tallest twin towers to this day. The buildings’ design motifs are inspired by Islamic art and culture; for example, the shape of each tower is the Muslim symbol of Rub el Hizb, or two overlapping squares that form an eight-pointed star. Both structures house commercial and business concerns and symbolize the architecture of modern business.
Figure 7.38 | Petronas Twin Towers, Malaysia
Author: User “Morio”
Source: Wikimedia Commons
License: CC BY-SA 3.0
In the late twentieth century, architectural ingenuity, new materials, and the potential of computer design led some architects to develop radically innovative approaches to structures that might house any number of different types of needs. Among the most innovative in this regard is Frank Gehry (b. 1929, Canada, lives USA), who has designed buildings all over the world including museums, business towers, residences, and theaters.
In Los Angeles, he created the Walt Disney Concert Hall, completed in 2003. (Figure 7.39) Using titanium sheathing for multiform, swooping curvilinear forms and volumes, his buildings are sculptural in effect from a visual standpoint. Yet in each case, his buildings have proven effective and dynamic in creating spaces for the activities they house. The acoustics of the concert hall are widely praised as is the beauty of the architectural form in capturing the whimsical spirit of Walt Disney, the creator of so many American comics, cartoons, and movies.
Figure 7.39 | Walt Disney Concert Hall, Los Angeles, CA
Author: John O’Neill
Source: Wikimedia Commons
License: GFDL
7.6 WORSHIP
Structures for worship, as we have noted, were sometimes combined with or were near those created for other communal needs. We saw this with the ziggurat, in the Roman forums, and in palaces, among others. But we also have a considerable history of architecture intended solely for religious purposes. From early times, there were two distinctive conceptions for a sacred building: whether it was a house for the deity or a house for the worshippers. Beyond that, it might be for individual devotional activities or for accommodating a congregational group. We can keep these points in mind when examining the types of building designed for these goals.
Among the earliest examples are the pyramid complexes from ancient Egypt. (Figure 7.40) The pyramids were tombs composed of millions of large stones in mathematically regular geometric structures carefully oriented to the stars. Pyramids evolved over thousands of years out of pre-Egyptian burial practices that began with placing heavy stones over gravesites to protect the occupants and their grave goods buried within.
Figure 7.40 | Rendering of the Giza Pyramid Complex, Egypt
Author: User “MesserWoland”
Source: Wikimedia Commons
License: CC BY-SA 3.0
The Egyptians created these elaborate and massive groupings of buildings for the royal dead on the west bank of the Nile River, creating a necropolis, or city of the dead. At Giza, the body of the pharaoh or other royal family member was brought down the river from the palace to the valley temple on the edge of the pyramid precinct. After priests mummified the body of the deceased and prepared it for entombment, the body would be taken to a mortuary temple near the pyramid. (Figure 7.41) That temple was the site where ceremonies were carried out at the time of the mummy’s placement within the pyramid, as were the perpetual rituals required to honor the king in the afterlife.
Figure 7.41 | Giza Pyramids
Author: Ricardo Liberato
Source: Wikimedia Commons
License: CC BY-SA 2.0
There were also temples for the living that the king would have had commissioned and served. One example is the Temple of Horus at Edfu, which has a number of typical features, although it was built relatively late in Egyptian history. It is of the pylon type, so named for the two upright structures that form its monumental façade and flank the main ceremonial portal. (Figure 7.42) The approach to temples was often along an avenue of sphinxes, imaginative hybrid creatures, part human, part animal, that led to the main door. Beyond the pylon wall was an open courtyard (Figure 7.43) and then a hypostyle hall, a structure with multiple rows of columns that support a flat roof, leading to the sanctuary. Typical of many sacred structures is this sort of staged progression by which one moves from the public or profane spaces through gradually more sacred, and often more restricted, areas that lead ultimately to the most sacred and reserved part. It is often the case that only priests or otherwise consecrated and dedicated persons are allowed in the sanctuary, the innermost and holiest space, while most of the congregation or worshipers are confined to less sacred parts of the temple, and the general public may be denied access to the premises altogether.
Figure 7.42 | Temple of Horus, Edfu
Author: User “ljanderson977”
Source: Wikimedia Commons
License: Public Domain
Figure 7.43 | Inside the Edfu Temple
Author: User “Than217”
Source: Wikimedia Commons
License: Public Domain
Greek temples like that devoted to Hephaestus in Athens, Greece, were not congregational at all. (Figure 7.44) They were designed as houses for the deity with a cella, or room, inside that was provided for the cult statue. Sometimes, there was also a cult treasury room within the temple, but ceremonies and sacrifices were conducted outside in the temple courtyard. Like the ziggurats, Greek temples incorporated the belief that the gods were on high, in the celestial realms, so they were often located in an acropolis, or sacred city high on a hill.
Figure 7.44 | Temple of Hephaestus, Athens
Author: User “sailko”
Source: Wikimedia Commons
License: CC BY-SA 3.0
This can clearly be seen in the case of the Parthenon, dedicated to the goddess Athena, the patron of the city of Athens. (Figures 7.45 and 7.46) As in all Greek temples, a mathematical relation can be found ordering the size and relation of the Parthenon’s elements. The length to width of the structure, the height to the width, the diameter of the columns, and their spacing all conform to the golden ratio of 4 to 9. This use of a single relation between the various elements of the structure gives it an aesthetically pleasing, unified, and more solid appearance, as does the use of several optical corrections. The columns lean slightly inward, and the stylobate, the base upon which the columns stand, bows upward slightly in the middle, both to give the appearance of being completely straight and flat.
Figure 7.45 | The Acropolis of Athens, Greece
Author: User “Salonica84”
Source: Wikimedia Commons
License: Public Domain
Figure 7.46 | The Parthenon, Athens, Greece
Author: Steve Swayne
Source: Wikimedia Commons
License: CC BY 2.0
Roman temples were often built in emulation of those of the Greeks, but they made many practical changes to the designs and often placed them in the center of the community, as opposed to the separated locations preferred by the Greeks. An important and very innovative temple design was created during the early Imperial era to honor the pantheon of nine planetary deities. To address the honor of the group, rather than individual gods, this temple, the Pantheon, took a different form. (Figure 7.47)
Figure 7.47 | The Pantheon, Rome, Italy
Author: Roberta Dragan
Source: Wikimedia Commons
License: CC BY-SA 2.5
The building had a traditional temple front made up of columns supporting a triangular pediment. Rather than continuing into a rectangular, gableroofed structure, however, the interior was an open circle with cult statues arrayed around its perimeter, each in a separate niche, or shallow recess in the wall. (Figure 7.48) That circular interior, acting as a drum, supported a huge domed space with an oculus, a circular opening, at its summit. Combining the circles of drum and dome creates a perfect sphere (diameter = height). (Figure 7.49) The whole of the structure was constructed using the ingenious Roman concrete, which allowed the creation of an unsupported dome— greatly facilitated by the use of coffers, or recessed squares, which tremendously reduced the dome’s weight. The circle and square are not only featured in the ceiling construction, the repetition of those shapes is carried out in all of the architectural and decorative elements of the Pantheon’s interior and exterior.
Figure 7.48 | Interior of the Pantheon, Rome
Artist: Giovanni Paolo Panini
Author: Google Cultural Institute
Source: Wikimedia Commons
License: Public Domain
Figure 7.49 | Cross-section of the Pantheon in Rome
Author: User “Cmglee”
Source: Wikimedia Commons
License: CC BY-SA 3.0
In addition to these singular features, the Pantheon was the first temple structure the congregation was allowed to enter. Once Christianity supplanted the ancient Roman religions, spaces with large, open interiors would be needed to house the faithful attending mass. The Pantheon served the needs of a Christian church well, and it was converted in 609 CE. Its adaptation as a Christian church prevents our viewing it as it was intended to be used, but the Pantheon still stands in well-preserved condition and with little alteration to the structure and basic décor of fine marbles for the floor and interior columns, due to its continuous service as a house of worship since it was built in the second century CE.
Some of the earliest evidence of worship in India shows that it was conducted in caves; we also see attempts to create worship spaces by excavating the living rock and creating larger caves for this purpose. While rock-cut architecture exists in many places around the world, its extent in India over the centuries is unsurpassed and, due to its great durability, many fine examples of it are preserved. A very early example is the Lomas Rishi Cave in the Barabar Hills from the third century BCE. (Figure 7.50) Because it is unfinished, we have a good idea of the methods and plans for the excavation, which included the addition of a large rectangular chamber leading into a smaller circular one. The sculptural treatment of the frame of the portal is a good example of the ways in which early architecture and decoration in stone imitated prior work in impermanent materials such as wood, as was the case for early architectural design around the world. Here, the designs simulate lattice, beams, and bentwood construction.
Figure 7.50 | Lomas Rishi Cave
Author: User “Neilsatyam”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Later Indian worship structures such as the Brihadeshwara Temple dedicated to the Hindu god Shiva, from the eleventh-century Chola Dynasty era, show the great complexity of conception of this type of worship space. (Figure 7.51) The tower at the far end is over the garba griha, or sanctuary, and as with the Temple of Horus at Edfu, there is staged progression from the profane (everyday) space to the most sacred. The whole is raised on a platform, a feature also seen in many sacred structures. Here, one must begin the approach by entering a gated courtyard, then ascend the stairs, and pass through the mandapa, or audience hall, before approaching the sanctuary. Outside the main temple but within the courtyard are subsidiary temples and shrines, as the worship is polytheistic, that is, with a great number of diverse deities.
Figure 7.51 | Brihadeshwara Temple, India
Author: User “Abhikanil”
Source: Wikimedia Commons
License: CC BY-SA 3.0
As is the case with most Hindu and Buddhist temples, although there are certainly ceremonial and ritual functions that are priestly duties, there is no restriction for lay people entering the sanctuary as the relationship to the deity is generally considered to be a personal one, not mediated by a priesthood.
The coexistence of Hindu and Buddhist deities evidenced by their shrines appears at many sites, though usually one or the other predominates at a given site. In addition to temples, another basic structure associated with Buddhism is the stupa. (Figure 7.52) One of the oldest stupas is in India where Buddhism first arose, at Sanchi in Madya Pradesh. Established in the third century BCE, it was conceived as a burial mound of a type, as it was believed to contain part of the earthly remains of Sakyamuni, founder of Buddhism. Surrounded by a tall stone fence, it is designed for the devotee to enter the fenced area and circumambulate, or walk around, the stone-faced, rubble-filled mound.
Figure 7.52 | Sanchi Stupa, Madhya Pradesh
Author: User “Ekabhishek”
Source: Wikimedia Commons
License: CC BY-SA 2.0
A great deal of symbolism is associated with the form including a yasti, or mast, rising from the center of the dome that stands for an axis mundi, or axis of the world, separating the earth from the sky above. The fence and gateways are also covered with mythological carvings related to Buddhist and Hindu beliefs. (see Figure 4.23) When the Buddhist stupa form migrated to China, Japan, and elsewhere, the design evolved to include native architectural traditions resulting in the stupa form becoming the multi-tiered pagoda, a Hindu or Buddhist sacred building.
Centers for Islamic worship are housed in architectural structures known as mosques. While churches and temples associated with other faiths are generally oriented to the four cardinal directions, usually with the altar toward the east where the sun rises, the mosque will always be situated so that the worshippers face in the direction of the qibla, a fixed wall aligned to face Mecca, the city that is the epicenter for Islam. This orientation remains consistent regardless of where in the world the building is set. While several different standard architectural forms exist for a mosque, its most common distinguishing exterior feature is the minaret, the slender tower from which the call to prayer is issued. The Sultan Ahmed Mosque shows six minarets while four are common at other sites. (Figure 7.53)
Figure 7.53 | Sultan Ahmed Mosque, Istanbul, Turkey
Author: User “Dersaadet”
Source: Wikimedia Commons
License: CC BY-SA 3.0
The most basic architectural form for Christian congregational churches is the basilica, a structure of longitudinal plan adapted from the Roman public building form. (Figure 7.54) The Roman basilica had an entrance on one long side that led to the large open interior space, the nave. The Christian basilica, unlike that used by the Romans, has an entrance on one end, is divided into a center nave and side aisles along its length, and holds a semi-circular apse, or recess, containing the altar at the opposite end of the longitudinal building from the entrance. (Figure 7.55) As in other centers for worship we have seen, the holiest part of the church is farthest away from the most profane or public spaces. The progression from one end of the church to the other is a processional ritual, enhanced by the long rows of columns flanking the nave, the long exterior walls, that were often heavy wood or masonry structures until the Gothic era, and the filtered light that played among the structural components.
Figure 7.54 | Diagram of old St. Peter’s Basilica
Author: User “Locutus Borg”
Source: Wikimedia Commons
License: Public Domain
Figure 7.55 | Basilica of Sant’Apollinare in Classe, Italy
Author: Angela Rosaria
Source: Wikimedia Commons
License: CC BY-SA 3.0
This was the case in Old St. Peter’s Basilica in Rome, (Figure 7.56) built in the fourth century CE on the model of the Roman basilica type. Also based on the Roman secular model was an atrium that was placed before the entrance. The original St. Peter’s was the center of the Christian world for centuries and a model for church architecture, but it was replaced during the Italian Renaissance and Baroque periods with the much grander structure that exists today in Rome.
Figure 7.56 | Drawing and reconstruction of the Constantinian Basilica, Rome
Artist: H. W. Brewer
Author: User “Lusitana”
Source: Wikimedia Commons
License: Public Domain
Christians in the Western Roman Empire used the basilica, or Latin cross, plan, but those in the Eastern Roman Empire, more commonly known as the Byzantine Empire, also employed the central plan, which had its origins in the circular plan, such as that used for the Pantheon. In the West, however, the circular, or central plan, church was used for a palace church such as Charlemagne’s at Aachen, (Figure 7.57) mausoleum (tomb building), or martyrium (site marking the death of a martyr, someone who died for their faith), where the placement of the altar does not need to address large crowds.
Figure 7.57 | Floorplan of Aachen Chapel
Artist: Georg Dehio
Author: User “Fb78”
Source: Wikimedia Commons
License: Public Domain
Perhaps the most familiar basilica or Latin Cross churches are those in the Gothic style in Europe that began in 1144. (Figure 7.58) When these structures were being built, they were not called “Gothic.” Instead they were called “opus francigenum” or “work of the Franks” because of its origination at the Abbey of Saint-Denis. The term “Gothic” was coined in the sixteenth century, originally meant as an insult, by artist and historian Giorgio Vasari (15111574, Italy). He wanted to distinguish the architectural style, based on forms from ancient Greece and Rome at that time practiced in Italy, from medieval Christianity and its associations with the destruction of classical learning and culture. The Goths were Germanic tribes that he believed had invaded and destroyed the refined culture of ancient Rome. His pejorative name has persisted but without its originally negative connotation.
Figure 7.58 | Floorplan of Amiens Cathedral
Artist: Georg Dehio
Author: User “Mattis”
Source: Wikimedia Commons
License: Public Domain
That first Gothic architecture was seen in the rebuilt choir at that Abbey Church of St. Denis, outside Paris, France, that was designed by the Abbot Suger and completed in 1144. (Figure 7.59) Several of the defining features of the Gothic cathedral were used there: the pointed arch, the ribbed vault, flying buttresses, and stained glass windows. Unlike the Roman circular arch, the Gothic or pointed arch is formed by two arcs with parallel sides. (Figure 7.60) A ribbed vault is formed at the intersection of two barrel vaults, with stone ribs sometimes added to support the weight of the vaults. The flying buttress is a load-bearing component located outside the building, connected to the upper portion of the wall in the form of an arch. (Figures 7.61 and 7.62) The combination of the pointed arch, ribbed vault, and flying buttress allowed the height of the interior spaces to be dramatically increased and the thickness of the outside walls dramatically decreased. This development led to the widespread use of stained glass throughout the church and the addition of the rose window, a circular stained glass window dedicated to the Virgin Mary, usually found above the main portals. (Figure 7.63) The much larger number and size of windows allowed natural and multicolored light to flood the interior of formerly dark churches as was the case at St. Denis. (Figure 7.64)
Figure 7.59 | Basilica of St. Denis
Author: User “Ordifana75”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.60 | Roman Arch/Gothic Arch Diagram
Author: Jeffrey LeMieux
Source: Original Work
License: CC BY-SA 4.0
Figure 7.61 | Diagram of flying buttress of the Cathedral Basilica of Our Lady of Amiens
Author: User “BuzzWikimedia”
Source: Wikimedia Commons
License: Public Domain
Figure 7.62 | Bourges Cathedral
Author: User “sybarite48”
Source: Wikimedia Commons
License: CC BY 2.0
Figure 7.63 | Reims Cathedral, France
Author: Magnus Manske
Source: Wikimedia Commons
License: CC BY-SA 1.0
Figure 7.64 | Ambulatory of the Basilica of St. Denis
Author: User “Beckstet”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Gothic churches were built throughout continental Europe and England, with regional variations, in the center of their communities usually, especially if they were cathedrals, or Bishop’s churches. Whether viewed from a distance approaching a town or standing within the cathedral itself, the building soared above all others as it reached to the heavens. They were filled with architectural and sculptural ornamentation to teach the doctrines of the Church, Bible stories, and the accounts of Mary, the Apostles, and the other saints. Portals were especially the focus of sculptural effort. Standing figures in high relief of prophets, kings, and saints graced the sides of the jambs, or upright supports to either side of a door. (Figure 7.65) And many other sacred and secular figures, relief sculptures, often of Jesus and symbols of the Four Evangelists, Matthew, Mark, Luke, and John, were included in the tympanum above the doors. (Figure 7.66) The architects, masons, and sculptors responsible for these monumental buildings were highly skilled and creative, and Gothic cathedrals remained the dominating forms of the Western urban landscape until the late nineteenth and early twentieth centuries when the modern structural steel skyscraper surpassed them in height and scale.
Figure 7.65 | Martyrs, Chartres Cathedral
Author: User “Ttaylor”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Figure 7.66 | Central tympanum of the Royal portal of Chartres Cathedral
Author: Guillaume Piolle
Source: Wikimedia Commons
License: CC BY 3.0
The overall effect of walking into a Gothic cathedral is to be drawn upward into a vast, light, and airy space, and to be dislocated from the physical and drawn into the spiritual. (Figure 7.67) This effect is the epitome of the Gothic Christian view that the physical and sensual world is to be ignored or even disdained in favor of chastity, spiritual awareness, and religious devotion.
Figure 7.67 | Nave of the Salisbury Cathedral, Wiltshire, UK
Author: User “Diliff”
Source: Wikimedia Commons
License: CC BY-SA 3.0
Christian churches of all denominations today generally follow the basilica model, but the sanctuaries vary considerably for diverse ceremonial practices. The Gothic type, with its pointed arches and glass windows that filter mystical light into the interior, is still common.
One example of an updated version is Thorncrown chapel, designed by E. Fay Jones (1921-2004, USA). Jones created a number of elegantly simple nondenominational chapels set into nature that let in diffuse light. (Figures 7.68 and 7.69) A pupil of Frank Lloyd Wright, Jones was inspired by Wright’s principles of using simple, local materials to thoroughly integrate structure and setting. The most striking feature at Thorncrown, located in Eureka Springs, Arkansas, is the structure’s light airiness. The whole of the interior for each of Jones’s chapels is a small sanctuary that seems entirely at home in the forest.
Figure 7.68 | Thorncrown Chapel
Architect: E. Fay Jones
Author: Clinton Steeds
Source: Wikimedia Commons
License: CC BY-SA 2.0
Figure 7.69 | Inside the Thorncrown Chapel
Architect: E. Fay Jones
Author: User “Bobak”
Source: Wikimedia Commons
License: CC BY-SA 2.5
7.7 BEFORE YOU MOVE ON
Key Concepts
We have seen architecture change throughout history in style, concepts, and purpose. However some aspects remain the same: its use for different purposes, expression of different types Specific in each instance to the particular patron or designer and to the purposes for the structure. Its uses for residential, commercial, communal or religious purposes, spiritual ideas, and sentiment.
This chapter allowed you to understand a broader range of methodologies in context of issues in modern art that evolved over time and with a world that became more complex. Architecture, other forms of art, has experienced great change in the designs of contrasting skyscrapers, incorporating more functionality and fluidity for the lives of modern people. Especially notable, perhaps, from our current perspective, are developments in art and architecture that occurred after World War II, when art’s focus moved from Europe to New York. With the focus on the West, art changed to incorporate more freedom in technique and style as opposed to rules that governed art and structures. Artists and architects are now committed to societal issues and personal expression in art and architecture, using all aspects of society to define and explain. This new construct reflects tradition and non-tradition, gives more voice on societal issues, expresses more culture, and resonates individual expression and identity and society’s aesthetic personality. Postmodern art focuses on public attention and its role in contemporary society by defining, questioning, and examining art’s function, form, content aesthetics, and value.
Test Yourself
Describe at least three different examples of architectural work – each built for a different purpose, and discuss specific features of the work that are designed to meet certain distinctive needs.
Discuss two different structures built for religious use, explaining how form is related to purposes, and how the form is used by that religious group. Be specific about how it meets particular ritual or other needs of the group.
Select four different types of architectural structures and explain the type of architecture and the purpose of each building. Discuss characteristics of each façade, and how the façade addresses the user of the building.
Describe different features of temple/church structures that reflect specific beliefs about the deity/deities of the people who use it for worship. Discuss why those particular features are logical and suitable for the ways they are used.
7.8 KEY TERMS
Acropolis: “high city” – a hilltop setting such as that reserved for the temple complex in ancient Athens associated with Classical Greece, including several temples to Athena and other sacred sites and structures. The elevated location is associated with greater proximity to the gods who were believed to reside in the celestial realms.
Aesthetics: the branch of philosophy that concerns itself with the definition of beauty and with considerations of the purposes and value of art.
Aisle: one of the longitudinal divisions of a basilica building. Basilica form churches usually have either three or five aisles, the central one being called the nave.
Amphitheater: a round or oval building with tiers of seats around a central area used for performances and sport events.
Arcade: a colonnade with arched spaces between the columns.
Art Functionalists: believe that form follows function and that the value of art consists in its function or performance.
Avatar: an embodiment of a deity on earth.
Avant-garde: new, original, and experimental.
Basilica: a building of longitudinal plan, originally designed for Roman law courts and public meetings, later adopted for Christian usage because of its suitability for accommodation of large congregations and processional ritual.
Bodhisattva: a Buddha-to-be; a being who has achieved enlightenment but has postponed Nirvana in order to help fellow seekers in their spiritual quests.
Cantilever: a long beam or other horizontal prop projecting from a wall to support a balcony, stairs, or similar structure.
Castrum: a Roman military encampment or fortress, specifically designed on a grid plan, with specific zones related to activities/uses.
Colonnade: row of columns supporting a roof or entablature.
Deity: a religion’s god or goddess.
Form: the structural components of a work of art or architecture.
Forum: open public space in Roman cities that served social, commercial, religious, and political needs of the residents.
Function: the meaning or purpose a work of art.
Gallery: a balcony or upper floor of a church or hall.
Garba Griha: Literally, the “womb” or most sacred precinct in a Hindu temple -the sanctuary.
Gothic: a late medieval (12th-14th centuries) architectural style that may include pointed arches, ribbed vaults, and flying buttress. Gothic churches have very tall structures, high interior spaces and, increasingly, the walls are filled with stained glass windows that filter mystical colored light into the interior.
Hypostyle hall: structure consisting of a “forest of columns” arranged in numerous rows that support a flat roof.
Iconography: the subject matter and/or symbolism of an artwork, including reference to religious or other narrative meaning.
Insula: an apartment building in the ancient Roman civilization.
Logo: a design used by an individual or organization to identify itself or its products.
Mandapa: an audience hall in Indian architecture, often a porch-like ante-room to a temple, but also a free-standing gathering hall.
Mausoleum: a building containing one or more tombs.
Middens: refuse heaps, often of kitchen waste, but also for other discarded materials.
Minaret: a tower, usually tall and slender, associated with a mosque and signifying Islamic presence in a location.
Oculus: “eye”; an opening in an architectural structure, to let in light, located in a ceiling, a dome, or on a wall.
Peristyle: a row of columns that surrounds a space such as a courtyard.
Post-and-lintel: basic architectural means of creating an opening in a wall by placing two vertical members (posts) to either side of the opening and spanning the upper part of the space with a horizontal member.
Propaganda: biased, and sometimes misleading or hidden, information intended to influence views, beliefs, or behavior.
Qibla: a wall in an Islamic mosque that is situated so that prayer is oriented towards Mecca.
Rammed earth: dampened earth mixed with sand, gravel, or clay that is compacted into a temporary frame to create a wall.
Sphinx: a hybrid human/animal sculpture.
Stele: an upright stone slab often serving as a grave marker or public monument.
Stoa: a covered walkway in a public area, often fronting market stalls or other commercial spaces.
Stupa: a domed, hemispherical structure that functions as a Buddhist shrine. The conception is of a burial mound, designed for ritual circumambulation.
Tympanum: the semicircular area above a doorway, often decorated with sculptural artwork, especially as noted in Romanesque and Gothic church portals.
Wattle and daub: branches intertwined with twigs and straw, then coated with a substance such as plaster or clay to create a wall.
Ziggurat: a man-made mountain, designed to be the platform for a temple, raising it closer to the heavens where the gods were believed to reside.
